ADVENTURE 03 256 Thermal Imaging Scope
The AD03 25/25 brings sensitive thermal imaging, versatile features, and rugged protection to first-time users. Its 256 × 192 detector, ≤25 mK thermal sensitivity, 25 mm F1.0 lens, and 50 Hz refresh rate reveal subtle temperature…
Model
AD03 25/25
Focal length
25mm / F1.0
FOV
7.0°x5.3°
Magnification
x14
Product features
Thermal imaging advantages
- 256 × 192 detector with 12 μm pixels and NETD ≤25 mK
- 25 mm F1.0 lens and 50 Hz frame rate
- 1024 × 768 AMOLED display
- Picture-in-Picture, hot-spot tracking and digital zoom
- Ballistic calculation, recoil-activated video and one-shot zeroing
- Photo/video recording and Wi-Fi connectivity
- At least 6 hours of battery life
- IP67 aluminum-alloy housing
Technical data
Specification table
| Product | ADVENTURE 03 Thermal Imaging Scope |
|---|---|
| Model | AD03 25/25 |
| Optics | |
| Focal length | 25mm / F1.0 |
| FOV | 7.0°x5.3° |
| Focusing mode | Manually |
| Display type | AMOLED |
| Display resolution | 1024 x 768 px |
| Display size | 0.39 inch |
| Eye relief | 45mm |
| Magnification | x14 |
| Sensor | |
| Type | Uncooled Vox |
| Resolution | 256 x 192 px |
| Pixel Pitch | 12μm |
| NETD | ≤25mk |
| Frame rate | 50Hz |
| ELECTRONICS | |
| Digital zoom | x1/2/4/8 |
| Palettes | White hot/ Black hot/ Red hot/ Iron red/ Hot spot tracking |
| Picture-in-Picture | Support |
| Ballistic caculation | Support |
| Recoil Activated Video | Support |
| One-Shot Zero | Support |
| Storage | 16/32G |
| Recording | Support photos and videos |
| WI-FI | Support |
| USB | Data export/ Charging |
| Battery Life | ≥6h |
| Start Up Time | 10 s |
| ENVIRONMENTAL/ WARRANTY | |
| Housing Material | Aluminum Alloy |
| Waterproofing | IP67 |
| Operating Temperature | -20℃~50°C |
| Storage Temperature | -40℃~70°C |
| Max. Recoil | 1000 g(300 Win./7mm Mag) |
